Humidity & Temperature Sensor Beacon (BC023-MultiBeacon) – with customizable T&H level triggers

  / by  Author
Humidity & Temperature Sensor Beacon (BC023-MultiBeacon) - with customizable T&H level triggers
Humidity & Temperature Sensor Beacon (BC023-MultiBeacon) - with customizable T&H level triggers - Image 2
Humidity & Temperature Sensor Beacon (BC023-MultiBeacon) - with customizable T&H level triggers - Image 3
Humidity & Temperature Sensor Beacon (BC023-MultiBeacon) - with customizable T&H level triggers - Image 4
Humidity & Temperature Sensor Beacon (BC023-MultiBeacon) - with customizable T&H level triggers - Image 5
Humidity & Temperature Sensor Beacon (BC023-MultiBeacon) - with customizable T&H level triggers - Image 6

$23.95

Our specialist humidity and temperature sensor compact beacon with customizable triggers based on temperature and humidity levels. With this beacon, you have accurate temperature and humidity sensing as well as the option to modify the beacon ID broadcast when the temperature or humidity has gone above or below customizable limits.

In stock

SKU: BC-023 Temp and Humidity Categories: , , , Tags: , , , , , , , , ,

Description

  • Our specialist humidity and temperature sensor compact beacon with customizable triggers based on temperature and humidity levels. With this beacon, you have accurate temperature and humidity sensing as well as the option to modify the beacon ID broadcast when the temperature or humidity has gone above or below customizable limits.
  • Broadcasts your choice of Sensor (T&H), iBeacon, Eddystone TLM, Eddystone URL, and/or Eddystone UID format. Eddystone TLM broadcasts battery strength, temperature, and broadcast count data. (This is NOT an Eddystone URL beacon for broadcasting your website or ad message to nearby phones. That service has been SHUTDOWN WORLDWIDE by Google as of Dec 6, 2018.)
  • Free configuration apps for iPhone & Android allow you to adjust settings according to your needs.
  • Transmit distance: 0.2-90 meters. Selectable TX levels: -40, -20, -16, -12, -8, -4, 0, +4dBm
  • Please contact us for step-by-step instructions.
  • This beacon is compatible with all bluetooth-capable smartphones as well as with our BLE beacon scanning gateway (Item BCG04)
Specifications:
Material for shell ABS
Color White/black/red/dark blue/orange/green
Size 36mm*36mm*5.6mm
Weight 10g
Accessory 3M tape
Battery CR2032 (replaceable)
Battery life >16 Months (Based on Broadcast Interval 1s and TX power 0dBm)
Waterproof level Splash resistence
Main Features
Support Protocol ◆Apple iBeacon
◆Eddystone URL
◆Eddystone UID
◆Eddystone TLM
◆Ksensor
OTA Support
Button YES
LED 2*LED
Sensor ◆Temperature sensor, error:+/-0.5℃ ,-40℃~70℃；
Rechargeable No (battery can be replaced )
Programmable parameters ◆Tx Power/Advtisement period/Lock password；
◆iBeacon UUID/Major/Mior；
◆Compatible with Eddystone, URL, UID(NamespaceID, SerialID)
◆KSensor
Buzzer N/A
Others ◆Support Non connection advertisment Mode
◆Support Configruation advertisment Mode
◆Support Factory reset
Physical features
Chipset nRF528xx serie
BLE5.0 BLE5.0, Supportable(High throughput, Advertising Ext, Improved coexistence)
Wireless Frequency Band 2.4GHz
Transmitting range  ◆BLE4.0/5.0 *90 meters in the open space.
The range depends on physical environment.
Powered by 3V CR2032 coin battery
Display way Beacon Gateway or via Phone App
Beacon Factory Default Setting
iBeacon ◆UUID: 0x7777772E-6B6B-6D63-6E2E-636F6D000001
◆MajorID:0x0001
◆MinorID: 0x0001
Tx Power 0dBm
Broadcast interval 1000ms
Eddystone UID ◆Namespace ID: 6B6B6D636E2E636FD01
◆InstanceID ID:0x000000000001
Eddystone URL URL: www.bluecharmbeacons.com
Eddystone TLM ◆Battery voltage;
◆Temperature;
◆Advertisements count/Time since power-up
Working environment
Working temperature -20℃ ~+65℃(default);
-30℃ ~+70℃(optional)
Storage  temperature 10℃~+25℃，≤65%RH





Feel free to contact us if you have any questions or would like to order in bulk (100-10,000 pieces)



Blue Charm Beacons ships within the USA via US Postal Service First-Class Package service.



International Orders:
International orders require a minimum of 3 pieces.

We ship to a limited number of countries outside the USA via UPS Worldwide Express, UPS Worldwide Expedited, or UPS Worldwide Saver. Delivery times for each different service differs from country to country, so please check the UPS website for delivery estimates. Typically it ranges from 2-5 business days. You will be offered a choice among the available services for your destination country during the order checkout process.

Note that the customer is responsible for any processing and import duties in their destination country. If you have any questions about this process, please contact UPS in your destination country. Note that our products’ country of origin is China.

If your country is not currently on our list of international shipping destinations, please contact us to have us add it.

Alternatively, you are welcome to sign up for one of the many package forwarding services in the USA, and we will ship your order to your specified USA forwarding service address so that they may forward it to your international address. eBay and Amazon also ship to some countries outside the USA.

FCC Compliance Statement

Additional information

Weight 0.6 oz
Dimensions 2.6 × 2.6 × 0.625 in
