Beacon Scanner Gateway (BCG04)

  / by  Author

$29.95

The BCG04 Mini BLE Gateway scans for BLE beacons within range and then transfers that data (via MQTT or HTTP over wifi) to the cloud for your access and analysis. This allows for tracking of assets as well as various automation triggering functions. Note: This gateway is only compatible with 2.4GHz wifi networks

In stock

SKU: BCG04 Category: Tags: , , , , , , , ,

Description

The BCG04 Mini BLE Gateway scans for BLE beacons within range and then transfers that data (via MQTT or HTTP over wifi – only compatible with 2.4GHz wifi networks) to the cloud for your access and analysis. This allows for tracking of assets as well as various automation triggering functions.

How the gateway works

Features:

Data collecting and uploading.

60 data packets collected per second.

Supports storing up to 1000 data packets when the network is unstable then uploads this stored data once the network is stable again.

Multiple filtering methods to effectively capture targeted data.

Specifications:
Size: 38 * 24 * 10.8 mm
Material: ABS
Power supply: USB power (not included)
Working Temperature: -30℃~75℃
Number of Received Broadcast Packets: 60 packets/second
Scan Coverage: 70 meters
This gateway is only compatible with 2.4GHz wifi networks



Feel free to contact us if you have any questions or would like to order in bulk (100-10,000 pieces)



Blue Charm Beacons ships within the USA via US Postal Service First-Class Package service.


International Orders: We no longer ship internationally due to a high percentage of fraudulent orders. You are welcome to sign up for one of the many packaging forwarding services in the US, and we will ship your order to your specified USA package forwarding address so that they may forward it to your international address.

FCC Compliance Statement

Additional information

Weight 3 oz
Dimensions 3 × 2 × 1 in
