Rugged Outdoor Beacon Scanner BLE Gateway (BCG03) with LTE3G/4G

  / by  Author
Rugged Outdoor Beacon Scanner BLE Gateway (BCG03) with LTE3G/4G
Rugged Outdoor Beacon Scanner BLE Gateway (BCG03) with LTE3G/4G - Image 2

$310.00

The BCG03 BLE Gateway (with LTE 3G/4G) scans for BLE beacons within range and then transfers that data (via MQTT or HTTP over wifi to the cloud for your access and analysis. This allows for tracking of assets as well as various automation triggering functions.

PLEASE CONTACT US TO SPECIAL ORDER THIS ITEM.

Out of stock

SKU: BCG03 Category: Tags: , , , , , ,

Description

The BCG03 BLE Gateway (with LTE 3G/4G) scans for BLE beacons within range and then transfers that data (via MQTT or HTTP over wifi to the cloud for your access and analysis. This allows for tracking of assets as well as various automation triggering functions. Price does not included shipping.

PLEASE CONTACT US TO SPECIAL ORDER THIS ITEM.



Please see the Quick Start Guide for this gateway in order to understand the set up and usage of this item before ordering. This is a commercial product.

Features:

  • Ultra-Long Range: BLE5.0 PHY Code, built-in LNA/PA, up to 1500 meters working range
  • Multiple Transmission Channels: WiFi, Ethernet network connection, LTE Cellular 3G/4G
  • Flexible Filtering Functions
  • High Security: Supports E2E security protocol, WPA2, 802.1x Enterprise, HTTPS/MQTT TLS encryption
  • Easy Maintenance: Web portal on smartphone & PC, OTA support, remote configuration from the Cloud or local
  • GPS: Real-time location tracking and data upload
  • Data offline storage: Data saved offline and uploaded after network connection restored
Specifications:
Basic Specifications

Model: BG03 WATERPROOF BLUETOOTH GATEWAY

Size: 220mm*110mm*75mm

Weight: 350g

IP Rating: IP67, designed for outdoor use

Material: ABS/PC

Power Supply: DC 9 ~ 12v/1A or 802.3af POE

Interface: RJ45 port or DC 9V, 1 nano SIM card (optional)

Working Temperature: -30℃~+75℃

Indicator: RGB LED indicator (internal)

Working Humidity: 5% ~ 95%RH

WiFi Specifications

WiFi Protocols: IEEE 802.11b/g/n

WiFi Frequencies: 2T2R 2412 MHz ~ 2484 MHz

Data Transfer Speed:

IEEE 802.11n: Up to 300 Mbps

IEEE 802.11g: Up to 54 Mbps

IEEE 802.11b: Up to 11 Mbps

Transmission Power:

IEEE 802.11n: 13 ~ 16 dBm

IEEE 802.11g: 14 ~ 17 dBm

IEEE 802.11b: 16 ~ 20 dBm

Receiving Sensitivity:

HT40 MCS7 : -69dBm@10% PER(MCS7)

HT20 MCS7 : -71dBm@10% PER(MCS7)

54M: -75dBm@10% PER

11M: -88dBm@ 8% PER

Modulation Mode:

DSSS (DBPSK, DQPSK, CCK)

OFDM (BPSK, QPSK, 16-QAM, 64-QAM

Network Protocol:

HTTP(SSL/TLS)

MQTT(SSL/TLS)

Wireless Encryption:

WPA-PSK/WPA2-PSK, WPA-EAP/WPA2-EAP and TKIP

 Bluetooth Specifications

BLE Protocol: BLE4.0, BLE4.1, BLE4.2, BLE5.0

Wireless Distance:

BLE4.x/BLE5.0 @1 Mbps: up to 400 meters (open line of sight)

BLE5.0 PHY Coded @125 Kbps: up to 1500 meters (open line of sight)

Scanning Ability: >260 packets per second

Transmission Method: ETH RJ45, Wi-Fi, LTE(3G/4G)

RX Sensitivity:

-108dBm @1Mbps, 0.1 %BER

-115dBm @125kbps, 0.1 %BER

Transmit Power: 18 dBm (Max)

Antenna Gain: 3 dBi

LTE/cellular Specifications

Versions:

EC25-E: Europe/Middle East/Africa/Korea/India

EC25-AU: Australia/New Zealand/Taiwan/Latin America

EC25-J: Japan

EC25-AF: North America

Data Transfer Speed:

LTE FDD: 150Mbps(DL)/50Mbps(UL)

LTE TDD: 130Mbps(DL)/30Mbps(UL)

Output Power:

Class 3 (23dBm±2dB) for LTE-FDD bands

Class 3 (23dBm±2dB) for LTE-TDD bands

SIM card: Nano sim card

GNSS: GPS / Glonass / Beidou

Positioning accuracy: 30 meters
Feel free to contact us if you have any questions or would like to order in bulk (20 or more pieces; price discounts available at 20 pieces and 100 pieces)



Blue Charm Beacons ships within the USA via US Postal Service First-Class Package service.



International Orders:
International orders require a minimum of 3 pieces.

We ship to a limited number of countries outside the USA via UPS Worldwide Express, UPS Worldwide Expedited, or UPS Worldwide Saver. Delivery times for each different service differs from country to country, so please check the UPS website for delivery estimates. Typically it ranges from 2-5 business days. You will be offered a choice among the available services for your destination country during the order checkout process.

Note that the customer is responsible for any processing and import duties in their destination country. If you have any questions about this process, please contact UPS in your destination country. Note that our products’ country of origin is China.

If your country is not currently on our list of international shipping destinations, please contact us to have us add it.

Alternatively, you are welcome to sign up for one of the many package forwarding services in the USA, and we will ship your order to your specified USA forwarding service address so that they may forward it to your international address. eBay and Amazon also ship to some countries outside the USA.

Additional information

Weight 48 oz
Dimensions 12 × 9 × 8 in
